Lightroom series part 26: How to merge a series of exposures into a raw HDR shot

Lightroom tutorial HDR merge
(Image credit: Sean McCormack)

High Dynamic Range describes a photo with an exceptionally wide tonal range – beyond what a typical camera can capture in one shot. You’ll typically create an HDR file by merging a series of photo shots at differing exposures to get a photo with an increased range of tones.

Welcome to the 26th instalment of our Lightroom series, first published in Digital Camera magazine (see below for subscription offers).

If you are already a Lightroom user, you could discover some new tricks and processes you haven't tried yet. If you don't use Lightroom, then scroll down to the bottom where you'll discover how to get it and which Adobe Photography Plan is best.

When shooting landscapes, you often find that an exposure for the sky makes the ground too dark, and an exposure for the ground would blow out the sky. The solution is to take a shot for the sky, and a shot for the ground, and another somewhere in the middle would allow you to get a smooth transition.

A typical sequence could have anywhere from three to nine shots, covering a range of exposures from three stops overexposed to three stops underexposed.

There are several programs that deal with HDR. Even Photoshop can do HDR, but the 32-bit files created cannot be edited directly in Photoshop. You need to create a 16- or 8-bit version of the file that loses some of the benefit of the 32 bit HDR file.

Fortunately when you use Merge to HDR in Lightroom, you retain the same editing features of any raw file. This means you can use White Balance and have a huge range in Exposure control. Most of the Lens Profiles available are for raw files only, so your HDR file can benefit from them too.

• See more Lightroom tutorials

1. Compile your exposures

To see a larger version of these screenshots, click on the gadget in the top right corner. (Image credit: Sean McCormack)

Collect the images you want in the panorama together and select them in the Grid. From the Photo menu, choose Photo Merge and then HDR. This has the shortcut Ctrl+H, which is the same in both macOS and Windows.

2. Preview the results

(Image credit: Sean McCormack)

The Merge to HDR dialog will open and you’ll have a short wait while a preview is created. Once you’re happy, you can skip the preview by using the shortcut Shift+Ctrl+H to merge. Drag the edges of this dialog box to get a larger preview.

3. Align and Tone

(Image credit: Sean McCormack)

The first two options are Auto Align and Auto Tone. Auto Align will fix errors from handheld brackets, or accidental tripod movement. Auto Tone applies a tonal correction. It’s generally -100 Highlights and +70 Shadows, with +15 Whites and -15 Blacks, rather than being based on the image itself.

4. Deghost amount

(Image credit: Sean McCormack)

Anything that moves in your photo (for example, waves or clouds) can cause ghosting, which can show up as an artefact in the merged photo. If nothing is moving, leave this on None. Try the other options to see what looks the best if you have some movement.

5. Check and merge

(Image credit: Sean McCormack)

To check which areas are being replaced, turn on the Show Deghost overlay. You can click on the preview to zoom in slightly. Once you’re happy, click the Merge button. Lightroom will then merge the files in the background.

6. Finishing touches

(Image credit: Sean McCormack)

Because the HDR file is a DNG, you can apply a camera profile, like a Vivid or Landscape mode. You have full White Balance control, so you can easily warm the photo for a golden hour look, and do further edits to the file in Lightroom. Here I’ve also fixed the horizon and applied a lens profile.

Expert tip: HDR best practice

Lightroom tutorial HDR merge

(Image credit: Sean McCormack)

There are a few tricks to getting good shots for HDR Merge. With landscapes, your apertures tend to be stopped down for more depth of field. While your 0 exposure may be easily handheld, you may find that your -3 exposure is really long. For this reason, it’s best to always use a tripod to avoid camera shake.

Speaking of shutter speed, this is the only setting you should be changing to create your bracketed set. As aperture controls depth of field, this needs to remain the same. The only other option is ISO. As the different ISOs will have different noise patterns, you’ll get really strange noise ghosting in the HDR from this, which is best avoided.

The final consideration is that you’re not limited to three exposures. Some people do five, in two-stop intervals. Others do seven or nine in one-stop intervals. You can even do it from two photos, but you need to limit the range of exposures, as you’ve fewer options for ghosting with this limited approach.
